Automatic Liquid Packing Machine

Automatic liquid packing machine is widely used for packing various kinds of liquid. Such as pure water, milk, soybean milk, fruit juice, beverage, soy sauce, and wine. liquid of foods,medicine and chemicals, pesticide, shampoo, body foam bath lotion, facial cream, ingredient oil, fruit sauce, tomato ketchup and honey etc.

Related file download

Product Description

Automatic Liquid Packing Machine


Description Of Automatic Liquid Packing Machine

This automatic liquid packing machine is suitable for packing different kinds of liquid. such as pure water, milk, soybean milk, fruit juice, beverage, soy sauce, and wine. Bag-making, filling, sealing, bag-dividing, counting and other functions can be completed automatically and directly. With the PLC controller system, the packaging speed and length of bags can be set to some extent without further adjustment. The high sensitivity photoelectric color tracking and digital input of cutting position make the precision higher.

This automatic liquid packing machine is compact in structure, complete in control systems, comfortable in operation and high in automation. The contact part of the material is made of high quality stainless steel, which is corrosion resistant and easy to clean. Various liquid products such as drinking water, cooking oil, liquid soap, and other liquid products can use this machine to pack. Date coder is available and other options can be customized based on customer's request.


Technical Parameters Of Automatic Liquid Packing Machine

Model

AB-S100

Capacity (Pcs/min)

30-60

Packing range (ml)

5-100

Power(kw/V)

1.6/220

Length of bag (mm) (max)

150

Width of bag (mm) (max)

120

Dimension (L×W×H) (mm)

760*1380*1700

Weight(kg)

300


Precautions Of Automatic Liquid Packing Machine

Due to the rich variety of liquid products, there are also many types and forms of liquid product packaging machines. Among them, automatic liquid packing machine used to pack liquid food have higher technical requirements. Aseptic, hygienic and safe are the basic requirements of liquid food packaging machines. .

1. Before starting each time, check and observe whether there are any abnormalities around the machine.

2. When the machine is in operation, it is strictly forbidden to approach or touch the moving parts with your body, hands and head.

3. When the machine is in operation, it is strictly forbidden to extend hands and tools into the sealing knife seat.

4. It is strictly forbidden to switch the operating buttons frequently during normal operation of the machine, and it is strictly forbidden to frequently change the parameter setting value at will.

5. Long-term operation at super high speed is strictly prohibited.

6. It is forbidden for two people to operate the various switch buttons and mechanisms of the machine at the same time; the power should be turned off during maintenance and maintenance; when multiple people are debugging and repairing the machine at the same time, they must communicate with each other and signal to prevent accidents caused by incoordination.

7. When checking and repairing electrical control circuits, it is strictly forbidden to work with electricity! Be sure to cut off the power! It must be done by electrical professionals, and the machine is automatically locked by the program and cannot be modified without authorization.

8. When the operator is unable to stay awake due to drinking or fatigue, operation, debugging or maintenance is strictly prohibited; other untrained or unqualified personnel are not allowed to operate the machine.

Warning: For the safety of you, others and the equipment, please operate according to the above requirements.


Physical Picture Of Automatic Liquid Packing Machine

1


2


3


4


5


7
